Genset Model | 50HZ 1500RPM | Download | |||||
| Prime Power | Standby Power | Engine Model | Fuel Consumption | Cylinder | Displacement | ||
| KVA/KW | KVA/KW | L/h | |||||
| AC275-IV | 250/200 | 275/220 | NT855-GA | 53 | 6L | 10.8 |  |
| AC275-V | 250/200 | 275/220 | MTA11-G2 | 52 | 6L | 10.8 | |
| AC275-VI | 250/200 | 275/220 | NTA855-G1 | 59 | 6L | 14 | |
| AC275-VII | 250/200 | 275/220 | QSNT-G6 | 62 | 6L | 14 | |
| AC313-I | 275/220 | 313/250 | QSNT-G7 | 68 | 6L | 14 | |
| AC313-II | 275/220 | 313/250 | NTA855-G1A | 61 | 6L | 14 | |
| AC350-I | 313/250 | 350/280 | MTAA11-G3 | 61.3 | 6L | 14 | |
| AC350-II | 313/250 | 350/280 | NTA855-G1B | 68 | 6L | 14 | |
| AC350-III | 313/250 | 350/280 | NTA855-G2 | 68 | 6L | 14 | |
| AC350-IV | 313/250 | 350/280 | QSNT-G1 | 76 | 6L | 14 | |
| AC375 | 344/275 | 375/300 | NTA855-G2A | 72 | 6L | 14 | |
| AC388-I | 350/280 | 388/310 | NTA855-G4 | 75 | 6L | 14 | |
| AC388-II | 350/280 | 388/310 | QSNT-G2 | 80 | 6L | 18.9 | |
| AC413-I | 365/300 | 413/330 | NTAA855-G7 | 86 | 6L | 14 | |
| AC450 | N/A | 450/360 | NTAA855-G7A | 98 | 6L | 18.9 | |
| AC413-I | 365/300 | 413/330 | KTA19-G2 | 83 | 6L | 19 | |
| AC438 | 400/320 | 438/350 | QSNT-G3 | 70.5 | 6L | 18.9 | |
| AC500-II | 450/360 | 500/400 | QSK19-G14 | 99.7 | 6L | 18.9 | |
| AC500-III | 450/360 | 500/400 | KTA19-G3 | 97 | 6L | 18.9 | |
| AC562-I | 500/400 | 562/450 | KTA19-G3A | 106.9 | 6L | 18.9 | |
| AC562-II | 500/400 | 562/450 | KTA19-G4 | 107 | 6L | 18.9 | |
| AC562-III | 500/400 | 562/450 | QSK19-G13 | 109.5 | 6L | 19 | |
| AC630-I | 575/460 | 630/505 | QSK19-G12 | 128.3 | 6L | 19 | |
| AC630-II | 525/420 | 630/505 | KTAA19-G5 | 113 | 6L | 19 | |
| AC646 | 588/470 | 646/517 | QSK19-G6 | 129.6 | 6L | 19 | |
| AC650-I | 575/460 | 650/520 | KTAA19-G6 | 118.5 | 6L | 19 | |
| AC650-II | N/A | 650/520 | KTA19-G8 | 141.4 | 6L | 19 | |
| AC688-I | N/A | 688/550 | KTAA19-G6A | 155 | 6L | 19 | |
| AC688-II | N/A | 688/550 | KTAA19-G7 | 155 | 6L | 19.0 | |
| AC700 | 625/500 | 700/560 | KT38-G | 140 | 12V | 37.8 | |
| AC713 | 650/520 | 712/570 | QSK19-G4 | 143 | 12V | 19 | |
| AC750 | 688/550 | 750/600 | QSK19-G11 | 153.8 | 12V | 19 | |
| AC788 | 713/570 | 788/630 | KTA38-G1 | 160.4 | 12V | 38 | |
| AC800 | 725/580 | 800/640 | KT38-GA | 168.2 | 12V | 38 | |
| AC825-I | 750/600 | 825/660 | KTA38-G2 | 167 | 12V | 38 | |
| AC825-II | 750/600 | 825/660 | QSK38-G8 | 168 | 12V | 38 | |
| AC888-I | 800/640 | 888/710 | KTA38-G2B | 167.3 | 12V | 38 | |
| AC888-II | 813/650 | 888/710 | QSK38-G7 | 180 | 12V | 38 | |
| AC1000-I | 910/728 | 1000/800 | KTA38-G2A | 191 | 12V | 38 | |
| AC1000-II | 910/728 | 1000/800 | QSK38-G6 | 197 | 12V | 38 | |
| AC1100 | 1000/800 | 1100/880 | KTA38-G5 | 209 | 12V | 38 | |
| AC1108 | 1008/806 | 1108/887 | QSK38-G1 | 212 | 12V | 38 | |
| AC1250 | N/A | 1250/1000 | KTA38-G9 | 247.5 | 12V | 38 | |
| AC1258 | 1144/915 | 1258/1007 | QSK38-G2 | 235 | 12V | 38 | |
| AC1375-I | 1250/1000 | 1375/1100 | QSK38-G5 | 274 | 12V | 38 | |
| AC1375-II | 1250/1000 | 1375/1100 | KTA50-G3 | 254 | 16V | 50.3 | |
| AC1650-I | 1375/1100 | 1650/1320 | KTA50-G8 | 289 | 16V | 50.3 | |
| AC1650-II | 1375/1100 | 1650/1320 | QSK38-G19 | N/A | 12V | 38 | |
| AC1650-III | 1500/1200 | 1650/1320 | KTA50-GS8 | 308.8 | 16V | 50.3 | |
