Genset Model | 50HZ 1500RPM | Download | |||||
| Prime Power | Standby Power | Engine Model | Fuel Consumption | Cylinder | Displacement | ||
| KVA/KW | KVA/KW | L/h | |||||
| AC330 | 300/240 | 330/264 | QSL9-G5 | 63 | 6L | 8.9 |  |
| AC330-I | 300/240 | 330/264 | QSL9-G7 | 63 | 6L | 8.9 | |
| AC300 | 375/220 | 300/240 | QSL9-G9 | 57 | 6L | 8.9 | |
| AC284 | 259/207 | 284/227 | L9-G17 | 54 | 6L | 15 | |
| AC311 | 285/228 | 311/249 | L9-G18 | 74 | 6L | 15 | |
| AC330 | 301/241 | 330/264 | L9-G19 | 79 | 6L | 15 | |
| AC353 | 318/254 | 353/282 | QSM11-G4 | 67 | 6L | 15 | |
| AC450 | 409/327 | 450/360 | QSX15-G4 | 86 | 6L | 15 | |
| AC500 | 445/364 | 500/400 | QSX15-G6 | 95 | 6L | 28 | |
| AC550 | 500/400 | 550/440 | QSX15-G8 | 105 | 6L | 28 | |
| AC715 | 650/520 | 715/572 | QSK19-G4 | 136 | 6L | 28 | |
| AC725 | 656/525 | 725/580 | QSK23-G5 | 138 | 6L | 28 | |
| AC825 | 750/600 | 825/660 | QSK23-G8 | 157 | 6L | 23.1 | |
| AC900 | 810/648 | 900/720 | QSK23-G9 | 154 | 6L | 23 | |
| AC1006 | 931/745 | 1006/805 | KTA38-G6 | 192 | 12V | 30.5 | |
| AC1008 | 933/746 | 1008/805 | KTA38-G7 | 192 | 12V | 30.48 | |
| AC1100 | 1000/800 | 1100/880 | QSK38-G1 | 210 | 12V | 38 | |
| AC1250 | 1135/908 | 1250/1000 | QSK38-G2 | 238 | 12V | 37.8 | |
| AC1400 | 1275/1020 | 1400/1120 | QSK38-G3 | 267 | 12V | 50 | |
| AC1400-I | 1270/1020 | 1400/1120 | QSK38-G5 | 267 | 12V | 38 | |
| AC1400-II | 1270/1020 | 1400/1120 | KTA50-G7 | 267 | 16V | 38 | |
| AC1400-III | 1270/1020 | 1400/1120 | QSK50-G2 | 267 | 16V | 38 | |
| AC1520 | 1358/1086 | 1520/1216 | QSK38-G19 | 290 | 12V | 38 | |
| AC1540 | 1400/1120 | 1540/1232 | QSK50-G3 | 293 | 16V | 50.3 | |
| AC1700 | 1540/1232 | 1700/1360 | QSK50-G4 | 324 | 16V | 50 | |
| AC1700-I | 1540/1232 | 1700/1360 | QSK50-G12 | 324 | 16V | 50 | |
| AC1760 | 1625/1300 | 1760/1408 | QSK50-G14 | 324 | 16V | 50 | |
| AC1825 | 1650/1320 | 1825/1460 | QSK50-G7 | 348 | 16V | 50 | |
| AC1875 | 1713/1370 | 1875/1500 | QSK50-G13 | 357 | 16V | 50 | |
| AC1875-I | 1713/1370 | 1875/1500 | QSK50-G15 | 357 | 16V | 50 | |
| AC1875-Ii | 1713/1370 | 1875/1500 | QSK60-G10 | 357 | 16V | 50 | |
| AC2000 | 1875/1500 | 2000/1600 | QSK50-G16 | 381 | 16V | 60.2 | |
| AC2000-I | 1875/1500 | 2000/1600 | QSK60-G12 | 381 | 16V | 60.2 | |
| AC2250 | 2000/1600 | 2250/1800 | QSK50-G17 | 429 | 16V | 60.2 | |
| AC2250-I | 2000/1600 | 2250/1800 | QSK60-G11 | 381 | 16V | 60.2 | |
| AC2500 | 2000/1600 | 2500/2000 | QSK60-G18 | 476 | 16V | 60.2 | |
| AC2500-I | 2250/1800 | 2500/2000 | QSK60-G21 | 476 | 16V | 60.2 | |
| AC2750 | 2500/2000 | 2750/2200 | QSK78-G23 | 524 | 16V | 77.6 | |
| AC3000 | 2750/2400 | 3000/2400 | QSK78-G15 | 714 | 18V | 77.6 | |
| AC3000-I | 2750/2400 | 3000/2400 | QSK78-G16 | 714 | 18V | 77.6 | |
| AC3000-II | 2750/2400 | 3000/2400 | QSK78-G23 | 714 | 18V | 77.6 | |
| AC3500 | 31250/2500 | 3500/2800 | QSK95-G5 | 833 | 16V | 77.6 | |
| AC3763 | 3363/2690 | 3763/3010 | QSK95-G10 | 896 | 16V | 77.6 | |
